The revolutionary MAC2 series HD video inspection system from Scienscope merges the latest in HD video technology with the clearest macro video optics to provide an easy to use forward-looking inspection system for your most fatiguing and difficult to see quality processes.

The systems use a forward mounted 720p HD LCD monitor and camera with integrated image capture to an 8GB SD/USB card for comfortable inspection and click-of-a-button image capture. Improve quality, document supplier parts, and reduce eye and neck strain simultaneously.

Key Features

  • 60 fps Real-Tim High Definiation System
  • Capture image with a PC
  • 720p HD Camera and monitor combination with built-in SD card slot for quick image capture.
  • Navitar Zoom 7000 lens. 2X magnification doubler available (PN: CC-97-LN1-2X).
  • Try the NEW defused LED dome for inspection of highly reflective parts.
  • Perfect for delicate assembly applications and inspection.

———————————————————————————————————————————————————————————————-

CC-CMC-LCD10
10″ HD camera and monitor combination unit

  • 1280 x 800 resolution @ 60 fps (24-bit)
  • CMOS; 1/2.5″
  • Image capture without a PC
  • HDMI output with wide screen format
  • Multiple cross hairs for quick gaging
  • Super easy auto-white balancing for color accuracy
  • Sharp Clear Image
  • Remote Control

CMOS Camera Specifications

Sensor CMOS; 1/2.5″
Resolution 1280 x 800 @ 60 fps (24-bit), 16:10 Aspect Ratio
Frame Rate 60fps
Pixel Count 2 megapixel
Pixel Size 3.75 x 3.75 um
Color RGB (individual adjustment)
White Balance auto/manual
Exposure auto/manual
Contrast manual
Memory slot SD (Up to 32GB)
Memory Card SD/USB 2.0 Dual-Interface 2GB card included
Cross hair grid Up to 4 horizontal and 4 vertical
Power Lens mount 5-12VDC C-mount

Complete System Information Coming Soon!

New Product – AXI-5100C

Introducing Scienscope new automated x-ray component counter; the AXI-5100C. Download our PDF flyer here for more information. Thank you for visiting.

MPI Chooses Scienscope for it’s Exceptional Value !

Scienscope Testimonial MPI

The Scienscope X-Scope 6000 is a great value for a technologically advanced X-ray inspection system. We recently replaced an older competitor system and find that the X-Scope 6000 gives us an edge in getting challenging solder profiles developed for high mass boards with many hidden solder terminations. The quick process feedback, sharply focused images and easy-to-use software has made this machine a big hit with the engineering team! – Dane Wentworth, Senior Vice President, MPI

The X-Scope 6000 is a digital, fully programmable computer controlled X-ray inspection system that allows operators to program inspection and measurement routines with point-and-click ease. It features a high power, 130 kV micro-focus, sealed x-ray tube, 70° camera tilt for oblique extreme angle inspection and 1,000X system magnifiction. Scienscope also offers various 100 percent automated inline platforms such as the X-Scope 8000 to meet the needs of many different industries.
